Cavity Filler Ball Valve
Cavity filler design for sanitary applications.
- Size
- DN15-DN150 (1/2"-6")
- Pressure
- Class 150-600 / PN16-PN100
- Temperature
- -40°C to +230°C
- Material
- CF8M, CF3M, 316L
- Connection
- RF, Clamp, Butt Weld
- Standard
- API 608, 3A
For an accurate proposal, include size, pressure class, material, end connection, medium, temperature, quantity and any project specification.
Product overview
Design intent and service scope
Cavity filler ball valve minimizes dead space and product accumulation. Ideal for sanitary, hygienic, and high-purity applications.
Key design features
- Cavity filler design
- 3A certified
- CIP/SIP compatible
- Minimal dead space
Technical data
Product specifications
| Size | DN15-DN150 (1/2"-6") |
|---|---|
| Pressure | Class 150-600 / PN16-PN100 |
| Temperature | -40°C to +230°C |
| Material | CF8M, CF3M, 316L |
| Connection | RF, Clamp, Butt Weld |
| Standard | API 608, 3A |
| Body | A351 CF8M / 316L |
| Ball | A182 F316 / 316L |
| Stem | A182 F316 |
| Seat | PTFE, RPTFE |
| Actuator | Lever, Worm Gear, Pneumatic |
Service fit
Typical applications
Referenced standards and requirements
Standards shown here are product design references, not a claim that every size, material or configuration is covered by a certificate. Confirm the applicable edition and approval scope during quotation.
Available project documentation
Project-specific submissions can include a data sheet, general arrangement drawing, bill of materials, inspection and test plan, material certificates and test records when specified and agreed in the order.
