SMD Valves
Vannes à obturateur
Vanette à obturateur campus
Réseau ville.
- Size
- DN15-DN200 (1/2"-8")
- Pressure
- Class 150-600 / PN16-PN100
- Temperature
- -29°C to +180°C
- Material
- WCB, CF8M, Brass
- Connection
- RF, NPT, Threaded
- Standard
- API 599
For an accurate proposal, include size, pressure class, material, end connection, medium, temperature, quantity and any project specification.
Product overview
Design intent and service scope
Vanette à obturateur type campus réseau ville.
Key design features
- Quarter-turn operation
- Positive position
- Compact
- Low torque
Technical data
Product specifications
| Size | DN15-DN200 (1/2"-8") |
|---|---|
| Pressure | Class 150-600 / PN16-PN100 |
| Temperature | -29°C to +180°C |
| Material | WCB, CF8M, Brass |
| Connection | RF, NPT, Threaded |
| Standard | API 599 |
| Body | A216 WCB / A351 CF8M / Brass |
| Plug | A182 F316 / Brass |
| Seat | A182 F316 / PTFE |
| Actuator | Lever, Worm Gear |
Service fit
Typical applications
Oil & GasWaterChemicalFuel
Referenced standards and requirements
API 599ISO 9001CE
Standards shown here are product design references, not a claim that every size, material or configuration is covered by a certificate. Confirm the applicable edition and approval scope during quotation.
Available project documentation
Project-specific submissions can include a data sheet, general arrangement drawing, bill of materials, inspection and test plan, material certificates and test records when specified and agreed in the order.
Review OEM/ODM and quality controls →
Need a project-specific configuration?
