SMD Valves
闂搁榾
楂樻俯鐞冮榾
楂樻俯宸ュ喌涓撶敤璁捐銆?
- Size
- DN25-DN600 (1"-24")
- Pressure
- Class 150-600 / PN16-PN100
- Temperature
- -29°C to +550°C
- Material
- WC6, WCB, F91, F51, Inconel
- Connection
- RF, BW, RTJ
- Standard
- API 6D, API 608
For an accurate proposal, include size, pressure class, material, end connection, medium, temperature, quantity and any project specification.
Product overview
Design intent and service scope
姘翠笅宸ュ喌涓撶敤锛屽寮洪槻鑵愪笌娣辨按瀹夎涓撶敤鎵ц鍣ㄣ€?
Key design features
- High temp design
- Graphite packing
- Extended bonnet
- Fire-safe
Technical data
Product specifications
| Size | DN25-DN600 (1"-24") |
|---|---|
| Pressure | Class 150-600 / PN16-PN100 |
| Temperature | -29°C to +550°C |
| Material | WC6, WCB, F91, F51, Inconel |
| Connection | RF, BW, RTJ |
| Standard | API 6D, API 608 |
| Body | A217 WC6 / A182 F91 |
| Ball | A182 F316 / Stellite overlay |
| Stem | A182 F316 / Inconel |
| Seat | Graphite, Metal, Stellite |
| Actuator | Worm Gear, Electric, Pneumatic |
Service fit
Typical applications
Power GenerationSteamThermal OilCogeneration
Referenced standards and requirements
API 6DISO 9001CEAPI 607
Standards shown here are product design references, not a claim that every size, material or configuration is covered by a certificate. Confirm the applicable edition and approval scope during quotation.
Available project documentation
Project-specific submissions can include a data sheet, general arrangement drawing, bill of materials, inspection and test plan, material certificates and test records when specified and agreed in the order.
