寮规€ф寮忛椄闃€

寮规€ф锛岃ˉ鍋跨儹鑶ㄨ儉銆?

Size: DN50-DN1000 (2"-40")
Pressure: Class 150-1500 / PN16-PN250
Temperature: -29°C to +550°C
Material: WCB, CF8M, F91, WC6
Connection: RF, RTJ, BW
Standard: API 600

Request product quotation Download catalogs

For an accurate proposal, include size, pressure class, material, end connection, medium, temperature, quantity and any project specification.

Product overview

Design intent and service scope

寮规€ф缁撴瀯锛屽惛鏀剁儹鑶ㄨ儉锛屾彁鍗囧瘑灏併€傞€傜敤浜庢俯搴﹀彉鍖栧伐鍐点€?

Key design features

Flexible wedge
Thermal expansion tolerance
Improved seating
Full bore

Technical data

Product specifications

Size	DN50-DN1000 (2"-40")
Pressure	Class 150-1500 / PN16-PN250
Temperature	-29°C to +550°C
Material	WCB, CF8M, F91, WC6
Connection	RF, RTJ, BW
Standard	API 600
Body	A216 WCB / A217 WC6 / A182 F91
Gate	A182 F316 / F91
Stem	A182 F316 / F91
Seat	A182 F316 / Stellite
Actuator	Handwheel, Gear, Electric, Pneumatic

Service fit

Typical applications

SteamPower GenerationOil & GasThermal Systems

Referenced standards and requirements

API 600ISO 9001CE

Standards shown here are product design references, not a claim that every size, material or configuration is covered by a certificate. Confirm the applicable edition and approval scope during quotation.

Available project documentation

Project-specific submissions can include a data sheet, general arrangement drawing, bill of materials, inspection and test plan, material certificates and test records when specified and agreed in the order.
